Scientific Table Model Sieve Shaker

Get a Price/Quote

Product Details:

Mounting Type Table-top
Application Soil, aggregates, powder particle analysis
Measuring Range 20 micron 4 mm
Hardness Rigid metal build
Frequency 50 Hz
Accuracy Dependent on mesh precision, typically 2%
Display Type Analog timer or digital (model dependent)
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Scientific Table Model Sieve Shaker Product Specifications

Power Supply 230V AC, 50Hz
Max Height Approx. 55 cm (with stack)
Resolution As per sieve size
Port Size Standard sieve mounting ports
Capacity Up to 7 standard sieves plus pan and cover
Interface Type Manual controls
Automation Grade Semi-automatic
Response Time Immediate on start-up
Specimen Size Dependent on sieve size
Temperature Operating: 5C to 40C
Test Range Mesh sizes from 20 micron to 4 mm
Operating Voltage 230 V, single phase AC
Equipment Type Table Model Sieve Shaker
Humidity Up to 85% RH (non-condensing)
Features Corrosion-resistant body, heavy duty construction, easy clamping system, low noise operation
Control Mode Manual/Timer based control
Number of Specimens Multiple sieves can be stacked
Test Stroke Variable amplitude
Test Width Accepts standard 8 or 12 diameter sieves
Frequency 50 Hz
Test Speed Standard, adjustable motor-driven vibration
Accuracy Dependent on mesh precision, typically 2%
Display Type Analog timer or digital (model dependent)
Application Soil, aggregates, powder particle analysis
Measuring Range 20 micron 4 mm
Machine Weight Approx. 25 kg
Hardness Rigid metal build
Usage Granulometric particle size analysis
Mounting Type Table-top

Noise Level Less than 65 dB
Body Material Mild steel with powder coating
Safety Overload protection
Timer 0-60 minutes
Motor Type Universal motor, thermally protected
Clamping System Quick release/adjustable clamps
Sieve Diameter Compatibility Standard 200 mm & 300 mm
Vibration Mode Simultaneous vertical and horizontal movement
Operation Continuous or timed
Finish Chemical resistant paint

Product Description

Spotlight your lab's precision with the Scientific Table Model Sieve Shaker, now in Clearance! Buy Online to own this invincible and grand machine, engineered for dominant performance in granulometric particle size analysis. Built with a chemically resistant, mild steel body, it operates at less than 65 dB. The quick release clamps, universal motor with overload protection, and dual-mode vibration ensure reliability. Accepts up to 7 standard sieves (200 & 300 mm), and runs both timed or continuous tests. Control is seamless-manual or via timer-for consistent, accurate results every time.

Versatile and Robust Table Model Sieve Shaker

Perfect for laboratory and industrial applications, this table-top sieve shaker stands out for its semi-automatic operation and reliable manual or timer-based controls. Featuring a rigid, powder-coated mild steel body with corrosion resistance, it's ideal for soil, aggregates, and powder analysis. The easy clamping system and variable amplitude enable quick setup for granular size classification. Designed for busy environments, it's suitable for stacking multiple sieves (up to 7) and is trusted by researchers, traders, and suppliers across India.

Reliable Payments and Prompt Shipping for Your Equipment

Experience secure shipping when you purchase the Scientific Table Model Sieve Shaker. We ensure FOB dispatching from major Indian ports, with supply ability to swiftly meet order volumes. Flexible payment terms help you plan your procurement easily, and our shipping estimate guarantees your order will arrive safely and on time. Trusted by industry professionals, our streamlined process ensures your purchase is protected from payment to delivery-making it effortless to equip your lab with grand, invincible technology.

FAQ's of Scientific Table Model Sieve Shaker:

Q: How does the Scientific Table Model Sieve Shaker enhance granulometric analysis?

A: The sieve shaker combines simultaneous vertical and horizontal vibration to efficiently separate particle sizes, ensuring precise, reliable granulometric analysis for soil, aggregates, and powders.

Q: What materials is the shaker constructed from and how does it resist corrosion?

A: It is built from robust mild steel with a powder-coated finish and features chemical-resistant paint, making it ideal for harsh laboratory environments and long-term use.

Q: Where can I use this model, and what sample types is it suitable for?

A: This shaker is best suited for laboratories, research centers, and industrial facilities analyzing soil, aggregates, and a wide range of powders requiring particle size separation.

Q: What is the process for operating the table model sieve shaker?

A: Simply stack up to 7 standard sieves, secure them with the quick release clamps, set the manual or timer control, then start the machine for either a timed or continuous test, depending on requirements.

Q: When will my order be shipped after purchasing the sieve shaker online?

A: After secure online payment, your order is dispatched promptly from our FOB port in India, and you will receive a shipping estimate to track your equipment's arrival.

Q: How does the shaker minimize operational noise?

A: Through its engineered low-noise universal motor and powder-coated mild steel construction, it maintains a noise level below 65 dB for a quieter laboratory environment.
