Compression Testing Machine - Hand Operated Channel

Get a Price/Quote

Product Details:

Interface Type Mechanical, manual interface
Application Compression strength testing of cubes and cylinders
Resolution 1 kN
Display Type Dial gauge
Temperature Room Temperature (10C - 40C)
Features Sturdy channel frame, calibrated dial gauge, manual operation, easy specimen loading
Number of Specimens Single specimen per test
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Compression Testing Machine - Hand Operated Channel Product Specifications

Mounting Type Floor mounted
Operating Voltage Not applicable (hand operated)
Specimen Size 150 mm x 150 mm x 150 mm or 100 mm x 100 mm x 100 mm
Hardness Machine frame made from hardened steel
Usage Laboratory and field testing of concrete specimens
Equipment Type Compression Testing Machine - Hand Operated Channel
Test Range Up to 1000 kN (subject to model)
Power Supply Manual Operation (No external power required)
Humidity Ambient, non-controlled
Response Time Instantaneous manual display
Measuring Range 0 - 1000 kN
Test Stroke Up to 50 mm
Test Width 150 mm
Automation Grade Manual
Max Height Approx. 800 mm
Accuracy 1% of indicated value
Machine Weight Approx. 350 kg
Control Mode Hand Operated
Features Sturdy channel frame, calibrated dial gauge, manual operation, easy specimen loading
Temperature Room Temperature (10C - 40C)
Capacity 1000 kN (as per model)
Test Speed Variable, manual control
Number of Specimens Single specimen per test
Resolution 1 kN
Display Type Dial gauge
Application Compression strength testing of cubes and cylinders
Interface Type Mechanical, manual interface

Installation Type Requires flat stable floor area
Ram Travel 50 mm
Finish Powder coated, corrosion resistant
Piston Diameter 165 mm
Safety Features Overload protection, safety valve
Platen Size 165 mm diameter
Frame Construction Heavy-duty steel channel body for robust operation
Oil Reservoir Capacity 5 liters (for hydraulic hand operation)
Packing Wooden crate
Movement Type Manual lever operation
Calibration Supplied with calibration certificate
Service Support On-site setup assistance and maintenance available

Product Description

Elevate your testing standards with the Elite Compression Testing Machine - Hand Operated Channel, designed for enviable precision and robust performance. Crafted with a splendiferous heavy-duty steel channel frame, it offers remarkable durability and corrosion resistance. The exquisite manual lever operation ensures flexibility, while the powder-coated finish guarantees longevity. Add to Cart now to experience efficient calibration, variable test speeds, and instantaneous dial gauge display. Shop Now for unrivaled accuracy, overload protection, and easy specimen loading - the elite choice for concrete strength testing in laboratories and on-site.

Compression Testing Machine Advantage & Usage

This hand-operated channel machine delivers controlled, variable-speed compression testing for concrete cubes and cylinders. Its primary competitive advantage is a robust hardened steel frame with a reliable manual lever system, enabling precise, repeatable results with 1% accuracy. Ideal for laboratories and field use, the machine comes with a calibration certificate and overload protection, ensuring safety and dependability for compressive strength assessment. Its versatile specimen loading mechanism enhances efficiency for single specimen tests.

Main Export Markets & Delivery Process

Our Compression Testing Machine - Hand Operated Channel is widely exported across Asia, Africa, and the Middle East. Domestic orders in India are serviced with efficient order processing, prompt dispatching, and reliable transport services. Typical delivery time is within 2 to 3 weeks from confirmed order. We cater primarily to laboratory equipment suppliers and traders in the main domestic markets, focusing on safe wooden crate packing and on-site setup assistance for hassle-free installation.

FAQ's of Compression Testing Machine - Hand Operated Channel:

Q: How does the manual lever operation benefit users during compression tests?

A: The manual lever mechanism allows users to have complete control over test speed and pressure application, enabling precise results and easy handling for single specimen testing.

Q: What is the process for setting up the Compression Testing Machine?

A: Installation requires a flat, stable floor area. On-site setup assistance and maintenance support are available to ensure correct assembly and operational readiness for laboratory or field use.

Q: Where can the Compression Testing Machine be used effectively?

A: The machine is suitable for laboratory and field testing environments, particularly for concrete specimens such as cubes and cylinders, due to its robust design and portable, manual operation.

Q: What safety features are included in the machine's design?

A: Overload protection and a safety valve ensure user and equipment safety during testing by preventing excessive force application beyond the machine's rated capacity.

Q: How is calibration and measurement accuracy guaranteed?

A: Each machine is supplied with a calibration certificate, ensuring 1% accuracy of indicated value and reliable results verified through a calibrated dial gauge interface.

Q: When is the optimal time to order for export delivery?

A: For international shipments, placing orders at least 3 weeks before required delivery ensures proper processing, packing, and dispatching within our standard timelines.
